Quick answer: Choose loading ramps rated comfortably above your mini excavator's total loading weight — that's the operating weight from the spec plate plus bucket, attachments and operator. As a rule of thumb, a 1.7-tonne class machine needs at least a 2500kg-rated pair, a 2.5-tonne machine a 3000kg pair, and a 3-tonne machine a 4000kg+ pair or Australian-made Sureweld ramps sized to the machine. Never buy ramps rated exactly at your machine's weight.
Get this right and loading your digger becomes a calm, 60-second, one-person job. Get it wrong and you're risking the machine, the trailer and yourself. Here's how to nail it.
Work Out Your Mini Excavator's True Loading Weight First
The number that matters isn't the one in the sales brochure — it's everything that rolls up the ramp:
- Operating weight — from the spec plate on the machine, not memory. This usually includes a standard bucket and a full tank.
- Extra attachments — augers, rippers, tilt hitches and second buckets add real weight fast.
- The operator — you're on the machine while it climbs. Add your weight (and be honest, fellas!).
- Mud and debris — a caked undercarriage after a wet job can add a surprising amount.
Add it up, then pick a ramp rating with clear headroom above the total. A safety margin of around 20% is a sensible minimum — ramps live a hard life, and dynamic loads (a track slipping, a jerky movement mid-climb) briefly exceed static weight.
Mini Excavator Ramp Size Chart
| Machine class | Typical total loading weight* | Minimum ramp rating (pair) | Suggested length** |
|---|---|---|---|
| 1.7t mini excavator | 1.8 – 2.1 tonnes | 2500kg | 2.3m – 2.9m |
| 2.5t mini excavator | 2.6 – 2.9 tonnes | 3000kg – 3500kg | 2.9m – 3.2m |
| 3t mini excavator | 3.2 – 3.6 tonnes | 4000kg+ | 3.2m – 3.6m |
*Always confirm against your machine's spec plate and attachment weights. **Based on a typical plant trailer deck height of 600–750mm — higher decks need longer ramps.
Why Ramp Length Matters As Much As Capacity
A longer ramp gives a gentler angle. That means better track grip on the climb, less chance of the counterweight or blade grounding out at the transition, and a far less puckering ride for the operator. If your trailer deck sits higher than about 750mm, or your machine has low ground clearance, size up in length. Our guide on what size loading ramps you need covers measuring your exact setup step by step.
Rubber Tracks vs Steel Tracks: Match The Rung Design
Most mini excavators run rubber tracks, which need rungs designed for grip without chewing the rubber. The Australian-made Sureweld Rubber Series and Digga Easy Loader ramps are purpose-built for exactly this. Running steel tracks? You need the Sureweld Track Series — standard rungs won't survive steel grousers.
Mini Excavator Ramps For Sale In Australia
Every pair of excavator ramps at Ramped Up is made from marine-grade aluminium, genuinely load-rated, and backed by a full warranty, best price guarantee and 90-day returns — rated 4.7 stars by more than 800 Aussie buyers, with fast delivery to your door anywhere in Australia. Know your total weight? You're five minutes from the right ramp.
